- DPC Power Conditioners are Power Regenerators, not only Voltage Stabilizers.
It supports optimum performance on all quality equipment. - Maintains stable AC Voltage Output 230V }10% even if the line fluctuates between AC230V +10%/-20%.
- Clean Power Re-generator offers the Pure Sine Wave AC Power (Distortion less than 1%) with full isolation from Noisy Main Power Line.
- Pure AC Power rescues Audio/ Video Signal deterioration or Control system trouble due to highly distorted and noisy Power Supply.
- Sophisticated Multi-layer Protection Circuits maximizes Operation Safety and Reliability of connected products / systems.
-
- Excessive Current, Surge Voltage, Over Load and Thermal Protection Circuits built-in.
- Multi-step Forced Cooling System automatically selects adequate amount of fan cooling.
- Ultra Compact , Light Weight & Highly Efficient.
-
Efficiency Higher than 90% at rated Power Output Slim in 2U (90mm, 3-1/2") Height,with detachable Standard EIA Rack mount adaptor Compact Standard Full Size : 430 x 88 x 370mm Light Weight 9kg
- Various clean power requirements
-
1kVA Sequential A/B total Spreading the rush current by
A/B Sequential
Rated Power Capacity | 1kVA |
---|---|
Rated Output Voltage : 230V |
Less than }1.0% |
Output Frequency : 60Hz | Less than }1.0% |
AC Outlets | Total Clean power(Switched) 2 : 1kVA Total |
A Group@1 | |
B Group (3second delayed) 1 | |
Weight | 19 lbs 12oz (9kg) |
Dimensions (WxHxD) | 430 x 88 x 370mm 16-7/8" x 3-7/16" x 14-9/16" |
AC Power Cable | Detachable with Stopper |
